60,877,000تومان
149 عدد در انبار
| Brand | Asenware |
|---|---|
| Mains supply | 230VAC (-15%, +10%). 47 ~ 63Hz. Max current 0.8A |
| Operating Voltage Range | 18.5 ~ 30VDC |
| Recommended mains cable | Screened or standard/black mains cable, cable size 0.75mm2 |
| Power Rating | Imax.a=1.2A; Imax.b=2.6A; Imin=0.65A |
| Max. charging current | 1.2A |
| Max. battery supply current | 4A (when the Mains is disconnected) |
| Battery capacity | Max. capacity 2×12V/17Ah; Min. capacity 2×12V/12Ah |
| Quiescent current (full loaded) | < 0.4A |
| S.C. Out (+, -) | Output voltage 18.5~30VDC |
| Max. output current | 0.5A |
| Output Recommended type of cable | Plain unscreened cable, 1.5mm2 |
| Output Cable diameter | 1mm2 ~2mm2 |
| Max. number of sounders @50mA | 20 |
| Loop Out (+, -) Loop In (+, -) | Output voltage 6.5 ~ 30VDC, pulse |
| Loop type | Class A |
| Loop Recommended type of cable | Screened or unscreened twisted-pair, 1.5mm2 |
| Loop Transmission distance | ≤1000m |
| Loop Cable diameter | 1mm2 ~2mm2 |
| Approx. Dimensions of the panel (W×H×D) | 430×560×170mm |
| Approx. weight (without battery) | 14kg |
